| Marka | Nuova Fima |
| Ürün | 39GCN13CP501 |
| Tanım | basınç göstergesi |
| Sipariş kodu | OZH4059069 |
Nuova Fima markalı 39GCN13CP501 basınç göstergesi ürüne ait fiyat ve teslim sürelerini bildiren teklifimiz için lütfen bizimle iletişime geçin. Markaya ait 39GCN13CP501 kodu dışındaki diğer kod ve referanslar için de teklif almak isterseniz konusunda uzman satış personelimiz size teklif sunmaktan mutluluk duyacaktır. 39GCN13CP501 ürününe ait. Pdf dosyası veya katalog bilgisi talebiniz durumunda üretici firma ile temasa geçilip, eğer mevcut ise tarafınıza sunabilmekteyiz. Türkiye deki geniş dağıtım ağımız ile istemeniz durumunda ürünlere uygun şartlarda kapı teslim teklif de sunmaktayız.
YALNIZCA ORİJİNAL VE YENİ ÜRÜN SATIŞI YAPMAKTAYIZ.
Firmamız yetkili distribütörü değildir. Tüm hakları üreticilere ve resmi ortaklarına aittir.
(DRUSCHA-D-DIVERS,Pressure switch Type 03.30.AAFV.A.1.23F.,1 microswitch Type A, single standard,setting range: 6-250 bar,cable exit: 1/2" BSP female UNI 6125,process connection: 1/4" NPT female)
DRUMI-D-DIVERS Execution: all st.st. bourdon tube pressure gauge MGS 18/2 Mounting: direct diameter: DN 100 Range: 0- 100 bar (AAFP) Case material: bayonet-lock case in st.st. AISI 304 window material: glass with vacuum stop (F01) with diaphragm seal 04.2B0.5.4.43M.41F.D.BAI MGS 9/2B0 diaphragm seal in AISI 316L process connection: 1/2" NPT male in st.st. AISI 316L direct mounting stainless steel bolts and nuts Mnfr: NUOVA FIMA
Execution: all st.st. pressure gauge, MGS 20/A "SOLID FRONT" safety execution Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male Range: 0-100 kg/cm² Case material: Bayonet-lock case in st.st. Window material: Safety glass Accuracy: 1,0
Execution: all st.st. pressure gauge, MGS 20/A "SOLID FRONT" safety execution Mounting: direct Diameter: DN 100 Connection: M20 X 1,5 Range: 0- 0,6 kg/cm2 Case material: Bayonet-lock case in st.st. Window material: Safety glass Accuracy: 1,0
1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG
Pressure Gauge 6" Dial size. Range 0-10 PSIG, 1/2" Bottom Con.
Pressure gauge Type: 02.42.1.A.E.0/250mbar.41M Execution: all st.st. diaphragm pressure gauge Mounting: direct Diameter: DN 100 Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-250 mbar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: Kl. 1.6
Statistische Warennummer: 90262040 Glyzerin-Rohrfedermanometer nach EN 837-1 1.18.3.A.G.0/6 bar.41M.T32 Robuste CHEMIE-Ausführung, komplett aus Edelstahl Gehäusedurchmesser: NG 160 Anschluss G 1/2 B unten aus Edelstahl Messbereich: 0 - 6 bar (Teilung: 0,05 bar) Mediumberührte Teile aus Edelstahl AISI 316 Bajonettring-Gehäuse aus Edelstahl Gehäuse mit BLOW OUT (Überdruckentlastung) Deckscheibe aus Sicherheitsverbundglas Schutzart: IP 67 Güteklasse 1,0 NUOVA FIMA
Basınç göstergesi
Pressure gauge Type: 01.18.3.A.E.43M.Execution: all st.st. bourdon tube pressure gaugewith glycerine filling
183-100-D-DIVERS 01.18.3.D.E.43M.B
Statistische Warennummer: 90262040 Pressure gauge Type: 01.18.3.D.E.43M.B Execution: all st.st. bourdon tube pressure gauge, Glycerine filled Mounting: panel with bracket Diameter: DN 100 Connection: 1/2 NPT back in st.st.AISI 316L Range: -1 / +5 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: Kl. 1.0 Protection: IP 67
Pressure gauge Type: 01.18.2.A.E.43M.P01 Execution: all st.st. bourdon tube pressure gauge, MGS18/2/A/E fillable with silicone oil Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male bottom Range: 0-250 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: 1,0
Pressure gauge Type: 01.18.2.D.E.43M.P01 Execution: all st.st. bourdon tube pressure gauge, MGS18/2/D/E fillable with silicone oil Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male back Range: 0-250 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: 1,0
Pressure gauge Type: 1.18.2.A.G.41M Execution: all st.st. bourdon tube pressure gauge fillable Mounting: direct diameter: DN 150 Connection: 1/2" BSP male bottom Range: 0-16 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl.1,0 , Statistische Warennummer: 90262040
Digital Portable Manometer Series 2000 Type 2028P (Extended Version) For Pressure, Vacuum and Differential pressure Battery operated Hand-Held with LCD-Display Range: 0-1 bar (max. Overrange 2 bar) Display range: 0,0-199,9 mbar and 0-1000 mbar Accuracy: 0,15% rdg + 0,15% FSO +1digit Switchable to Pa, inH2O, mH2O, inHg, mHG, PSI (Display range acc. to data-sheet) Pressure ports: 2 x tube connection for tube 4 mm inner diam. / 6 mm outer diam. Display Backlight (switchable) Zero setting by keypress HOLD-Function Automatic Switch of the Display resolution can be deactivated MAX/MIN Memory Number of pushbuttoms: 8 Protection: IP 67 (with connected tubes) Battery Type: 2 x AA, 1,5 V (not included in delivery)
Pressure gauge Type: 01.20.3.A.G.ABFD.41M.L02 Execution: All st.st. bourdon tube pressure gauge, SOLID FRONT, Glycerine filled Mounting: direct Diameter: DN 150 Connection: 1/2" BSP male in st.st. AISI 316 L Range: 0-15 psi Case material: bayonet-lock case in st.st. AISI 304 Window material: safety glass Accuracy: Kl. 1.0 with adjustable pointer
pressure switch
