Marka | Stahl |
Ürün | p/n: 168710, Type: 7537/2-304 |
Tanım | Emniyet anahtarı |
Sipariş kodu | OZH4275697 |
Gümrük tarife numarası | 85365080 |
Teknik özellik | patlamaya karşı korumalı | Tip: 7537/2-304 | Muhafaza malzemesi: Polyester reçine Cam elyaf takviyeli | Detaylı direk sayısı: 3 kutuplu | Yardımcı kontak NC: 1 NC | Yardımcı kontak NO: 1 NO/Gecikmeli | Uygulama aralığı (bölgeler): 22 | Toz patlama koruması: II 3 D Ex tc IIIC T90° C Dc | min. ortam sıcaklığı: -20 °C | maks. ortam sıcaklığı: +40 °C | Koruma derecesi (IP): IP66 | Kulp rengi: Siyah örtü ve tutamak | Kablo rakoru: 2 x M40 Ø 16... 28 mm | 1 x M25 Ø 7... 17 mm | Ek cihaz: - | - | - | Aux. cont. conn. cross- bölüm: 0,5... 1,5 mm2 İnce telli | 0,5... 2,5 mm2 Katı |
Stahl markalı p/n: 168710, Type: 7537/2-304 Emniyet anahtarı ürüne ait fiyat ve teslim sürelerini bildiren teklifimiz için lütfen bizimle iletişime geçin. Markaya ait p/n: 168710, Type: 7537/2-304 kodu dışındaki diğer kod ve referanslar için de teklif almak isterseniz konusunda uzman satış personelimiz size teklif sunmaktan mutluluk duyacaktır. p/n: 168710, Type: 7537/2-304 ürününe ait. Pdf dosyası veya katalog bilgisi talebiniz durumunda üretici firma ile temasa geçilip, eğer mevcut ise tarafınıza sunabilmekteyiz. Türkiye deki geniş dağıtım ağımız ile istemeniz durumunda ürünlere uygun şartlarda kapı teslim teklif de sunmaktayız.
YALNIZCA ORİJİNAL VE YENİ ÜRÜN SATIŞI YAPMAKTAYIZ.
Firmamız yetkili distribütörü değildir. Tüm hakları üreticilere ve resmi ortaklarına aittir.
