Marka | Nuova Fima |
Ürün | DMU-S-D-DIVERS |
Tanım | Pressure sensor Type: 08.S18 Execution: pressure sensor with ceramic cell Accuracy: 0,5% F.S.V acc. to IEC 60770-Limit point Electrical connection: Male and female plug DIN 43650 Specification Code acc. to Data-sheet 08 = Electronics S18 = Pressure transmitter 0-600 bar = range 43M = process connection: 1/2 NPT male 10E = output: 4-20 mA, 2 wire / supply: 10..30 VDC Please check the process connection and output. It was not specified in the inquiry. |
Sipariş kodu | OZH4789301 |
Gümrük tarife numarası | 90322000 |
Teknik özellik | 8.ST1.----.AAFF.23M.1.FPM.PVC.V.MBG.C01 model st1. seramik transdüs hücresi, st st. AISI 316l soket., aralık 0... 20 bar, 1/4 “npt erkek proses bağlantı, 4... 20 ma çıkış sinyali. 2 tel bağlantısı, viton (fkm) conta contası, ip65 koruma derecesi kablo çıkışı, pvc kablo l = 1,0 mt, kablolama: ub:kahverengi 0v: beyaz gnd: gri, st. st. aisi 316l durumda, doğruluk ± 0,5% aralık, 1 döngü kalibrasyon raporu attn misisng aralığı attn eksik uzunluk pvc kablo |
Nuova Fima markalı DMU-S-D-DIVERS Pressure sensor Type: 08.S18 Execution: pressure sensor with ceramic cell Accuracy: 0,5% F.S.V acc. to IEC 60770-Limit point Electrical connection: Male and female plug DIN 43650 Specification Code acc. to Data-sheet 08 = Electronics S18 = Pressure transmitter 0-600 bar = range 43M = process connection: 1/2 NPT male 10E = output: 4-20 mA, 2 wire / supply: 10..30 VDC Please check the process connection and output. It was not specified in the inquiry. ürüne ait fiyat ve teslim sürelerini bildiren teklifimiz için lütfen bizimle iletişime geçin. Markaya ait DMU-S-D-DIVERS kodu dışındaki diğer kod ve referanslar için de teklif almak isterseniz konusunda uzman satış personelimiz size teklif sunmaktan mutluluk duyacaktır. DMU-S-D-DIVERS ürününe ait. Pdf dosyası veya katalog bilgisi talebiniz durumunda üretici firma ile temasa geçilip, eğer mevcut ise tarafınıza sunabilmekteyiz. Türkiye deki geniş dağıtım ağımız ile istemeniz durumunda ürünlere uygun şartlarda kapı teslim teklif de sunmaktayız.
YALNIZCA ORİJİNAL VE YENİ ÜRÜN SATIŞI YAPMAKTAYIZ.
Firmamız yetkili distribütörü değildir. Tüm hakları üreticilere ve resmi ortaklarına aittir.
Pressure gauge Type: 02.42.1.A.E.0/250mbar.41M Execution: all st.st. diaphragm pressure gauge Mounting: direct Diameter: DN 100 Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-250 mbar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: Kl. 1.6
Statistische Warennummer: 90262040 Glyzerin-Rohrfedermanometer nach EN 837-1 1.18.3.A.G.0/6 bar.41M.T32 Robuste CHEMIE-Ausführung, komplett aus Edelstahl Gehäusedurchmesser: NG 160 Anschluss G 1/2 B unten aus Edelstahl Messbereich: 0 - 6 bar (Teilung: 0,05 bar) Mediumberührte Teile aus Edelstahl AISI 316 Bajonettring-Gehäuse aus Edelstahl Gehäuse mit BLOW OUT (Überdruckentlastung) Deckscheibe aus Sicherheitsverbundglas Schutzart: IP 67 Güteklasse 1,0 NUOVA FIMA
Basınç göstergesi
Pressure gauge Type: 01.18.3.A.E.43M.Execution: all st.st. bourdon tube pressure gaugewith glycerine filling
183-100-D-DIVERS 01.18.3.D.E.43M.B
Statistische Warennummer: 90262040 Pressure gauge Type: 01.18.3.D.E.43M.B Execution: all st.st. bourdon tube pressure gauge, Glycerine filled Mounting: panel with bracket Diameter: DN 100 Connection: 1/2 NPT back in st.st.AISI 316L Range: -1 / +5 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: Kl. 1.0 Protection: IP 67
Pressure gauge Type: 01.18.2.A.E.43M.P01 Execution: all st.st. bourdon tube pressure gauge, MGS18/2/A/E fillable with silicone oil Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male bottom Range: 0-250 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: 1,0
Pressure gauge Type: 01.18.2.D.E.43M.P01 Execution: all st.st. bourdon tube pressure gauge, MGS18/2/D/E fillable with silicone oil Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male back Range: 0-250 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: 1,0
Pressure gauge Type: 1.18.2.A.G.41M Execution: all st.st. bourdon tube pressure gauge fillable Mounting: direct diameter: DN 150 Connection: 1/2" BSP male bottom Range: 0-16 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl.1,0 , Statistische Warennummer: 90262040
Digital Portable Manometer Series 2000 Type 2028P (Extended Version) For Pressure, Vacuum and Differential pressure Battery operated Hand-Held with LCD-Display Range: 0-1 bar (max. Overrange 2 bar) Display range: 0,0-199,9 mbar and 0-1000 mbar Accuracy: 0,15% rdg + 0,15% FSO +1digit Switchable to Pa, inH2O, mH2O, inHg, mHG, PSI (Display range acc. to data-sheet) Pressure ports: 2 x tube connection for tube 4 mm inner diam. / 6 mm outer diam. Display Backlight (switchable) Zero setting by keypress HOLD-Function Automatic Switch of the Display resolution can be deactivated MAX/MIN Memory Number of pushbuttoms: 8 Protection: IP 67 (with connected tubes) Battery Type: 2 x AA, 1,5 V (not included in delivery)
Pressure gauge Type: 01.20.3.A.G.ABFD.41M.L02 Execution: All st.st. bourdon tube pressure gauge, SOLID FRONT, Glycerine filled Mounting: direct Diameter: DN 150 Connection: 1/2" BSP male in st.st. AISI 316 L Range: 0-15 psi Case material: bayonet-lock case in st.st. AISI 304 Window material: safety glass Accuracy: Kl. 1.0 with adjustable pointer
pressure switch
00020 201071825 GAUGE:PRESS;0-10KG/CM2,1/8IN,NPT,2-1/2IN GAUGE: PRESSURE RANGE: 0-10 KILOGRAM PER SQUARE CENTIMETER CONNECTION SIZE: 1/8 IN CONNECTION: NATIONAL PIPE THREAD FACE SIZE: 2-1/2 IN CONNECTION LOCATION: LOWER MANUFACTURER: NUOVA FIMA MODEL NUMBER: 52240251060000 *PHOTOS ATTACHED* 00030 201090588 TRANSDUCER:ELECTRO PNEUMATIC,4 TO 20MA,%
TEMPERATURE GAUGE, RANGE 0-160C, APPLICABLE SERIAL NO 2758/02
TEMPERATURE GAUGE, RANGE 0-200C, APPLICABLE SERIAL NO 2758/06
thermostat
(Test- und Konformitätserklärung 3.1 von NUOVA FIMA)
DDM-DM-D-DIVERS 02.16.1.A.G.0/600 mbar.43M.C.S31.R10
Statistische Warennummer: 90262040 Differential pressure gauge Type: 02.16.1.A.G.0/600 mbar.43M.C.S31.R10 Execution: with double diaphragm Mounting:direct or with back flange diameter: DN 150 Lower Connections: 1/2" NPT male in st.st. AISI 316L Range: 0- 600 mbar static pressure: max. 100 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass case filling: glycerine 2" Stackes bracket accuracy: Kl. 2,5 %
