| Marka | Erichsen |
| Ürün | Test tip acc. to ISO 1518-1 |
| Sipariş kodu | OZH4857905 |
| Teknik özellik | (düz sıkıştırma alanı olmayan kısa mil), diğerleri arasında testler için GME 60280 Genel Motorlar/Opel, GMW 14688'e göre Genel Motorlar/Opel, PV 3952 Volkswagen/Audi, D45 1047 Renault, MS210-05K Hyundai/Kia, MS210-06K Hyundai/Kia, STD 4377 Volvo, vb. - Çizilme testi için |
Erichsen markalı Test tip acc. to ISO 1518-1 ürüne ait fiyat ve teslim sürelerini bildiren teklifimiz için lütfen bizimle iletişime geçin. Markaya ait Test tip acc. to ISO 1518-1 kodu dışındaki diğer kod ve referanslar için de teklif almak isterseniz konusunda uzman satış personelimiz size teklif sunmaktan mutluluk duyacaktır. Test tip acc. to ISO 1518-1 ürününe ait. Pdf dosyası veya katalog bilgisi talebiniz durumunda üretici firma ile temasa geçilip, eğer mevcut ise tarafınıza sunabilmekteyiz. Türkiye deki geniş dağıtım ağımız ile istemeniz durumunda ürünlere uygun şartlarda kapı teslim teklif de sunmaktayız.
YALNIZCA ORİJİNAL VE YENİ ÜRÜN SATIŞI YAPMAKTAYIZ.
Firmamız yetkili distribütörü değildir. Tüm hakları üreticilere ve resmi ortaklarına aittir.
dinamometre
1 Satz Bleistifte
Çelik atış (3,5 mm ila 5) elmas GH 06302
dinamometre aparatı
for leveling of the device by placing it on the housing. (Round Spirit Level to be Placed ontological the unit's housing, for leveling the unit).
COATING THICKNESS GAUGE MINI TEST 730 (ORDER NO. 0524.16.51)
with external SIDSP ® sensor for magnetic induction FN5/2.5 And eddy current method (F range 0 - 5000 microns / N 0 - 2500 microns) including soft case with belt clip and neck strap, 1 or 2 reference zero disk (s), 3 precision standards, Hand strap, 2 AA batteries (Mignon) and operating instructions (German / English / French / Spanish) and MSoft 7 Basic edition on CD-ROM, manufacturer certificate
COUNTERWEIGHT WITH DRAGONFLY ("LEVEL")
to fixate on the load arm. Counter Weight (to be fixed ontological the unit's load arm) with built-in tubular type of Spirit Level.
DIN 53 211, SIS 184115, SNV37 11 REFERENZKLASSE”aus Leichtmetall, mit Düsen-Ø 4 mm
Order number: 0062.05.31
Härteprüfstab, Modell 318 einschl. Prüfspitze Nr. 1 (nach Bosch, 0,75 mm Ø) und 3 Federn Best.-Nr.0020.01.31
Order number: 0620.02.51
Order number: 0620.01.51
Fallkörper: 2 pounds, Skala/Teilung: 80/2 inch pounds, Ø Kugel/Matrize: 5/8" / 0.64"
mit 6 Schneiden und Schnittabstand
Cutting element
Tauch-Auslaufbecher in Anlehnung an DIN ISO 2431 mit Düsen-Ø 6 mm
Çizilme sertliği
Mar Tester
Cutting element
with 6 blades and cutting distance 1 mm for cross-cut tests according to EN ISO, ISO, VDA, EN, with magnifier, Polyamide bristle brush and plastic case
mit 6 Schneiden und Schnittabstand
ISO 2808, BS 3900:C5 4 Teilmessbereiche: 5 - 100 μm ( 5 μm Skalenteilung) 100 - 300 μm (10 μm Skalenteilung) 300 - 700 μm (20 μm Skalenteilung) 700 - 1500 μm (40 μm Skalenteilung
Diamond probe according to DIN EN 438-2 and ISO 4586-2 (Cone angle 90 °, tip radius 90 microns)
ORDER NO. 0004.01.31 SHEET METAL TESTING MACHINE, MODEL 100
with manual operation, maximum drawing force 30 kN and compliance with the standard constant adjustable blank holder pressure max. 10 kN, with Tiefungsanzeige by counter with 0.1 mm Reading accuracy as well as a testing tool no. 27 by EN ISO 20482; for checking the drawability of sheet metal and bands from 0.1 to 1.5 mm thick (about 400 N / mm² tensile strength) in widths from 13 to 90 mm, by the Erichsen cupping test according to EN ISO, EURONORM, BS, NF, GOST, UNI, UNE. Weight: approx 36 kg net Dimensions: 340 x 350 x 450 mm (L x W x H)
ORDER NO. 0012.01.31 MODEL 102 SHEET METAL TESTING MACHINE
with electro-hydraulic drive, max. Pulling force of 60 kN and automatic test sequence with a stop at specimen failure (from 0.3 mm sheet thickness), for testing of sheet and strip any kind of pressure -, punching and deep drawing ability by means of the I. Erichsen cupping test according to EN ISO, EURO NORM, BS, NF, GOST, UNI, UNE, II. Bore Expanding sample (KWI) to Siebel and Pomp. The testing machine is equipped with automatic shut-off device and delay automatic execution in accordance with Technical Description 102 / D, a Cupping Tool No.. According to 27 EN ISO 20482 as well as a filling hydraulic oil equipped. Power supply: 400 V three-phase, 50 Hz, 1 kW (other voltages on request) Weight: about 280 kg net Dimensions: 650 x 680 x 1125 mm (L x W x H)
